Backpack COFDM Transmitter , Microwave A / V portable Wireless High Definition Multimedia Interface Video Transmitter Encrypted

Name: Backpack COFDM Transmitter Microwave A V portable Wireless High Definition Multimedia Interface Video Transmitter Encrypted
Brand: SUNTOR
Price: 1 USD

Wholesale Backpack COFDM Transmitter , Microwave A / V portable Wireless High Definition Multimedia Interface Video Transmitter Encrypted from china suppliers

Brand Name : SUNTOR

Model Number : ST9502T

Place of Origin : Shenzhen, China

MOQ : 1 set

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 set/ month

Delivery Time : 7-15 days

Certification : FCC, CE, RoHS

Price : Negotiation

Packaging Details : Plastic Box

Video Coding : H.264

Range : LOS/NLOS

Video : High Definition Multimedia Interface and CVBS

Duplex Data : RS232

Bandwidh : 2/3/4/5/6/7/8 MHz

Encryption : AES256

Power : DC12V

Weight : 1.6kg

Contact Now

Backpack COFDM Transmitter , Microwave A / V portable Wireless High Definition Multimedia Interface Video Transmitter Encrypted

Backpack COFDM Transmitter, Microwave A / V portable wireless video transmitter Encrypted

Specification Sheet

Introduction

ST9502T wireless video transmitters series are based on MPEG-II and H.264 encoding technology, the HD digital wireless video transmission equipment was first developed in 2011. The system uses 300-900MHz frequency, advanced COFDM, QPSK, QAM modulation technology, highly improves the transmission, disturbance and the combination of the image quality , the high transmission specifically comes to more than 5KM .

Features

BNC video interface, 1920P*1080P high quality video
Strong safety with AES 256 bit encryption
Integrative design of back-pack, 10A battery, and robust transmitter
Compact design, low consumption and low latency
Support NLOS and fast moving environments but stable signals transmission
Easy operation by digital panel configuration, and LCD display
Designed in -grade level
Support transmitter function customized (including video interface, RF power, frequency, Battery volume, add data & two way audio function etc.)

Backpack COFDM Transmitter , Microwave A / V portable Wireless High Definition Multimedia Interface Video Transmitter Encrypted

Video transmitter
Frequency/Video	300-900 MHz, 1.2GHz/2.4GHz/4.4GHz (option)
Frequency/Data	200-860 MHz/(option)
Constellation	QPSK, 16QAM
RF Power	10W
Voltage	DC12V
Modulation	COFDM
Bandwidth	2/2.5/4/8 MHz(adjustable)
FEC	1/2,2/3,3/4,5/6,7/8
Guard Interval	1/32,1/16,1/8,1/4
AV Input (BNC)	Video: for analog camera connection
AV Input (BNC)	Audio: Analog stereo left and right channels
Video Compression	H.264
Data encryption	AES 128/256 bits
RF Interface	UHF
Video Format	High Definition Multimedia Interface and PAL/NTSC(auto adaptation)
Data interface	1 ports, RS485/RS232/TTL @1200/2400/9600/19200pbs
Flatness	Full band＜2dB, 8MHz＜2.5dB
Carrier	2K, 8K
Video resolution	720P
Case Material	Aluminum alloy, Rain-proof
Work environment	-30~70℃
Size	20013060mm
Weight	1.2kg
